Miniature Dial Gauges

Dimension

Miniature Dial Gauges

0.001mm, 0.005mm, and 0.01mm

	These compact size dial gauges are equipped with small dial faces.
	They are especially useful for measuring jigs, in restricted areas.

Model	36B
Graduation	0.01mm
Range	3mm

Contact point ( X-107 )
Lug back

Model	47
Graduation	0.01mm
Range	4mm

Contact point ( X-107 )
Lug back
Dial dia. Ø36mm

Model	47F
Graduation	0.01mm
Range	4mm

Contact point ( X-107 )
Flat back
Dial dia. Ø36mm

Model	47SZ
Graduation	0.01mm
Range	0.8mm

Contact point ( XB-1 )
Flat back

Model	36A
Graduation	0.005mm
Range	3mm

Contact point ( X-107 )
Lug back

Model	57S
Graduation	0.01mm
Range	5mm

Contact point ( X-105 )
Lug back
Dial dia. Ø39mm
